61
ECS Gen. 1
Solenoid valve
block - drive axle
(4x2 tractor)
1/3. Supply air from - and drain to - drive axle valve, 6035C
4. Air supply from wet tank
21. Air to and from LH front air bellows
22. Air to and from RH front air bellows
The solenoid block for 4x2 tractors contains 2 solenoid
valves:
- SID 3 the RH valve - air to and from RH and LH air
bellows.
- SID 7 the ʻcentralʼ valve - operating as a control valve.
