Standard STD 101-0001
Volvo Group
Version
4
Page
11
Figure 9 – Thickness indicator for a non-modelled thin part
4.3 Common requirements for product-definition data
4.3.1 General
This section establishes the common requirements for the application, display management and query of product
definition data. Specific requirements for particular types of product-definition data are given in sections 4.4 to 4.9.
4.3.2 Common requirements
4.3.2.1 Display management
Display management shall include the ability to enable or disable the display of annotations
completely, by type or selectively.
