5
DIGITAL MUSIC CORPORATION
Connections
Power
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
To use the supplied Power Adaptor, plug the body of the
adaptor into a suitable power receptacle. Then plug the cable
into the jack marked "Power" on the Ground Control.
If you have the GCX Guitar Audio Switcher, you don't need to
use the supplied power adapter. The GCX will phantom power
the Ground Control through a standard 5-pin MIDI cable.
If you are not using the GCX, but have a device that supports
phantom power via a 7-pin MIDI cable, this device can power
the Ground Control. Connect the 7-pin MIDI cable from your
Ground Control's MIDI Out to the 7-pin MIDI In on the
device. Then connect the Ground Control's Power Adaptor to
the phantom power jack on the device.
MIDI
¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯¯
Connect a 5-pin MIDI cable from the Ground Control MIDI
Out to the MIDI In of your first device. If you are using the
GCX, it should always be your first device.
If you have additional devices, connect the MIDI Thru of the
first device to the MIDI In of the next device. If the device has
no MIDI Thru, then use its MIDI Out. Continue to chain your
devices until they are all connected. If you are chaining more
than three devices, using a MIDI Thru box like the Digital
Music MX-28S will eliminate possible data errors.
