6 Button Interface

The button control panel and the LCD are designed to be the normal user

interface. The LCD is used to display each of the menu items, the current

operating state, the progress of the current command, and to acknowledge the

command status information. The button panel consists of the following three

buttons:

Button Function Description

Yellow Menu This button is designed to step through each of the

menu or parameter items. It always steps in a

forward direction.

Green Enter This button is designed to either select a menu or

parameter item, or acknowledge status information.

Red Cancel This button is designed to either abort the entering of

a new command or the execution of the previous

command.

The button command menu is organized into a series of levels and parameter

values. When displayed, the command information is displayed on the top line of

the LCD and the parameter information on the next line. The level information is

separated from the command information using a colon (e.g., [1:System Test]

refers to level 1, and a command of “System Test”). Each of the parameters

associated with a particular command (e.g., Wipe Enabled, Wipe Disabled) are

displayed under the command once it has been selected. The prompting

hierarchy used to organize the set of supported commands follows:

Level Prompt Description

1 System Test Perform a system test.

2 Clone Drive Perform a clone drive operation.

SHA Disabled Disables the verification of each target drive

after the clone operation has finished (default).

SHA Re-Verify Enables the verification of each target drive after

the clone operation has finished.

Wipe Enabled Enables wiping the unused area of a target drive

(default).

Wipe Disabled Disables wiping the unused area of a target

drive.

3 Verify Drives Verify all drives contain the same data.

4 Wipe Drives Perform a wipe drive operation.

5 Remove HPA Remove HPA from target drives.

6 Remove DCO Remove DCO from target drives.

Whenever commands are entered from the button control panel, all status

information must be acknowledged by the operator. A special arrow character
