SET SCREWS
aka the root of all issues
Insert both set screws and use thread
locker on all set screws.
Use a high quality hex driver to prevent
the hex prole from stripping. Ball-end
drivers are not recommended.
Loose set screws account for the majority
of issues that our users report. Save
yourself hours of troubleshooting and
apply thread locker to all set screws
during the build.
See the products application notes for
instructions - keep away from printed
parts.
GT2 20T 9mm wide Pulley
5x60 Shaft
POSITION AS SHOWN
Make sure one of the set screws is
oriented with the D cut, as shown in
the image.
BELT DRIVE ASSEMBLY
To Next Page
