VORON 2.4 - Pulley and Shaft Assembly

03
WWW.VORONDESIGN.COM
625 Bearing
GT2 80 Tooth Pulley
625 Bearing
625 Bearing
CHECK YOUR WORK
Compare your assembled parts to
the graphics shown here.
BELT DRIVE ASSEMBLY
APPLY THREAD LOCKER
Make sure to use thread locker on the
set screws.
M5 Shim
