VORON ERCF v2 - Heat Set Insert Guide

WWW.VORONDESIGN.COM
CAD version: ERCF V2
15
This design relies heavily on heat set inserts. If you’ve never worked with heat set inserts before, watch this guide :
https://www.youtube.com/watch?v=cyof7fYFcuQ
Here is a list of all the pages of this manual where you need to add the heatset inserts into the 3D printed parts, so you can
do this step all at once for the whole assembly :
• Page 27
• Page 32
• Page 41
• Page 84
• Page 85
• Page 86
• Page 96
• Page 106
Optionally, for the ERCT / CottonTail Buffer:
• Page 133
• Page 139
15
INTRODUCTION
HEAT SET INSERTS
