WWW.VORONDESIGN.COM
CAD version: ERCF V2
3030
GEARBOX
Gear_Box_Front
CHECK POINT
Make sure the 2020 extrusion is
fully seated against the stop built
into Gear_Box_Front.
2020 INSTALLATION
