CAD version: ERCF V2
HINGE UNLOCK
Use a small tool (like an allen key) inserted into the hinge hole
to free the print-in-place mechanism and ensure it rotates freely.
Do this for both latches.
3333
GEARBOX
[a]_Side_Latch_x2 †
LATCH PREPARATION
