Chapter 2 Product information IR610 high performance vector control frequency inverter user manual
- 6 -
IR610-1R5GT4B
3
5
4.2
5.6
1.5
al
IR610-2R2GT4B
4
5.8
5.6
9.4
2.2
IR610-4R0G/5R5PT4B
5.9
10.5
9.4
13.0
3.7
IR610-5R5G/7R5PT4B
8.9
14.6
13.0
17.0
5.5
SIZE B
IR610-7R5G/011PT4B
11
20.5
17.0
23.0
7.5
IR610-011G/015PT4B
17
26.0
25.0
31.0
11
SIZE C
Intern
al
IR610-015G/018PT4B
21
35.0
32.0
37.0
15
IR610-018G/022PT4B
24
38.5
37.0
45.0
18.5
SIZE D
IR610-022G/030PT4B
30
46.5
45.0
57.0
22
IR610-030G/037PT4
40
62.0
60.0
75.0
30
SIZE E
optio
n
IR610-037G/045PT4
50
76.0
75.0
87.0
37
IR610-045G/055PT4
60
92.0
90.0
110.0
45
SIZE F
IR610-055G/075PT4
75
113.0
110.0
135.0
55
IR610-075G/090PT4
104
157.0
152.0
165.0
75
SIZE G
IR610-090G/110PT4
112
170.0
176.0
210.0
90
Exter
nal
IR610-110G/132PT4
145
220.0
210.0
253.0
110
SIZE H
IR610-132G/160PT4
170
258.0
253.0
304.0
132
SIZE I
IR610-160G/185PT4
210
320.0
304.0
360.0
160
IR610-185G/200PT4
245
372.0
360.0
380.0
185
SIZE J
IR610-200G/220PT4
250
380.0
380.0
426.0
200
IR610-220G/250PT4
280
425.0
426.0
465.0
220
SIZE K
IR610-250G/280PT4
315
479.0
465.0
520.0
250
IR610-280G/315PT4
350
532.0
520.0
585.0
280
SIZE L
IR610-315G/355PT4
385
585.0
585.0
650.0
315
IR610-355G/400PT4
420
638.0
650.0
725.0
355
SIZE M
IR610-400G/450PT4
470
714.0
725.0
820.0
400
IR610-450G/500PT4
530
800.0
820.0
/
450
