IR610 high performance vector control frequency inverter user manual Chapter3 Product appearance and wiring

- 11-

Chapter 3 Product appearance and Installation Dimension

3.1 Product appearance and installation

3.1.1Product appearance

fan

Name plate

cover

Line board

Keypad

Fan cover

Back cover

Front cover

Main circuit terminal

Extension card port

Control terminal

3-1-1 0.75kw-15kw

3-1-2 18.5kw-90kw
