IR610 high performance vector control frequency inverter user manual Chapter2 production information
- 5-
Chapter 2 Product Information
2.1 Designation Rules
Name plate：
MODEL: IR610-2R2GT4B
POWER: 2.2kW/4.0kW
INPUT: 3PH AC380~440V 50Hz/60Hz
OUTPUT: 3PH 0~440V 0~600Hz 5.6A/9.4A
S/N:
TYPE
POWER
INPUT
OUTPUT
CODE
2-1 Name Plate
Model instruction：
2-2Model instruction
2.2Product series instruction
Table 2-1IR610 inverter models and technical data
Model
Power
capacity
(KVA)
Input
current
(A)
Output current(A)
Adapta
ble
Motor
(KW)
SIZE
Brake
Unit
Heavy
load
Light
load
Three phase: 380-480V，50/60Hz
IR610-R75GT4B
1.5
3.4
2.5
4.2
0.75
SIZE A
Intern
IR610 -2R2 – G T 4 B
T:three phase
Load type:G normal duty
Power，2R2 means 2.2kW
Product series
B means breaking units
4:380-480v three phase 2: 200-240v
