IR610 high performance vector control frequency inverter user manual Chapter 5 function code table
- 106 -
When P22.06 is set to 1, increasing this
setting vaule can reduce the electromagnetic
noise in the middle speed section.
50%～110%
It is used to define the duty cycle of the
inverter side IGBT. Overmodulation is allowed
when it is set to 100% or more, and the
allowable overmodulation is deepened when
the set value is increased from 101 to 110.
0:disabled
1:enabled
When the AVR function is enabled, the effect
of the DC bus voltage change on the output
voltage can be eliminated.
Energy braking voltage
funtion
0-Disabled
1-Enabled
2-only enable when ramp to stop
This parameter is only used to control the
built-in brake unit. For models without a
built-in brake unit, this setting can be ignored.
320V～400V(220V level )
600V～800V(380V level )
690V～900V(480V level )
950V～1250V(690V level)
0:No Operation
1:Output phase switch
(equal to change Phase between V and
W,For closed loop control, you need to
re-rotate the self-learning to confirm the
encoder direction)
Cooling method (fan
control)
0:Effective when running
1:Forced control( effective when power on)
2:Adjustable as per drive temperature
0-G type;1-P type
G means normal duty (constant torque
load)
P means light duty such as fan and
