- 125-
P40.11
PID feedback
source1
Unit’s digit 0：PID feedback source1(fdb1)
0:AI1
1:AI2
2:AI3(option card)
3:AI4(option card)
4: PLUSE(HDI)
5: Communication
6: Motor rated output current
7: Motor rated output frequency
8: Motor rated output torque
9: Motor rated output frequency
Ten’s digit : PID feedback source2 (fdb2)
Same as Unit’s digit
00
☆
P40.13
PID feedback
function selection
0:fdb1
1:fdb1+fdb2
2:fdb1-fdb2
3:fdb1*fdb2
4:fdb1/fdb2
5:Min(fdb1,fdb2)Take fdb1.fdb2 smaller
value
6:Max(fdb1,fdb2) Take fdb1.fdb2 bigger
value
7: (ref1+ref2)/2
8: fdb1and fdb2 switchover
0
☆
P40.14
PID output feature
0: PID output is positive: when the
feedback signal exceeds the PID
reference value, the output frequency of
the inverter will decrease to balance the
PID. For example, the strain PID control
during wrapup
1: PID output is negative: When the
feedback signal is stronger than the PID
reference value, the output frequency of
the inverter will increase to balance the
PID. For example, the strain PID control
during wrapdown
0
☆
