P07.08
DO6 Output terminal
function group(IO card)
28:Off loading
29:Reserved
30:Reserved
31: Reserved
32:Variable selector unit 1 output
33:Variable selector unit 2 output
34:Variable selector unit 3 output
35:Variable selector unit 4 output
36:Logic unit 1 output
37:Logic unit 2 output
38:Logic unit 3 output
39:Logic unit 4 output
40:Delaying unit 1 output
41:Delaying unit 2 output
42: Delaying unit 3 output
43: Delaying unit 4 output
44: Reserved
45: Reserved
0
☆
P07.09
VDO1(virtual DO1) output
Terminal function
0
☆
P07.10
VDO2(virtual DO2) output
Terminal function
0
☆
P07.11
Output logic negative
Define as per bit O:off;1:on(negative)
Bit0:DO1
Bit1:DO2
Bit2:Relay 1
Bit3: Relay 2
Bit4: DO3;Bit5: DO4 Bit6: DO5; Bit7: DO6
Bit8: VDO1;Bit9: VDO2
Notice:posive logic equivalent to Normal open
point
And negative logic equivalent to Normal close
point
0
☆
P07.12
DO1 effective delay time
0.000s～30.000s
0.000s
☆
