17
9 ASSEMBLY OF PLATE
FUELS
Fig. 12: ASSEMBLY OF PLATE FUELS
1. Inner Flue
2. Flue Connection Plate Fixing Screws
3. Flue Connection Plate
The outer and inner sheet metal ues are
assembled one within the other.
The cooker hood is set in the midst, and then
the ue connecting plate (3) is directly afxed to
the wall, under the cover or points E and F are
marked after performing a measurement. (Page
16 Fig.10)
Drill points E and F with Ø6mm drill bit, and in-
sert Ø6mm and plastic dowels. Insert the ue
connection plate with 3.9x22 screws (Page 16
Fig.10)
By pulling the inner ue (1) with screw (2) up-
wards and
left, screw it to the ue connection plate (3) on
the right and left (Fig.12).
ASSEMBLY OF PLATE FUELS
