EN - 9
English
Installation
SIP 1-Line Hidden Base with Cordless
Handset and Charger - CTM-S2115
Base station installation
This section assumes that your network
infrastructure is established and that your
IP PBX phone service has been ordered
and configured for your location. For more
information about IP PBX configuration,
please refer to the SIP Phone Configuration
Guide.
You can power the base station using a
compatible VTech power adapter (sold
separately) or using Power over Ethernet
(PoE Class 2) from your network. If you are
not using PoE, install the base station near a
power outlet not controlled by a wall switch.
The base station can be placed on a flat
surface or mounted on a wall in a vertical or
horizontal orientation.
To install the base station:
Plug one end of the Ethernet cable into the
Ethernet port on the rear of the base station
(marked by NET), and plug the other
end of the cable into your network router or
switch.
If the base station is not using power from a
PoE-capable network router or switch:
Connect the supplied power adapter to the
base station power jack.
Plug the power adapter into an electrical
outlet that is not controlled by a wall switch.
IMPORTANT INFORMATION
1. Use only a compatible VTech power
adapter. To order a replacement power
adapter, call +44 (0)1706 694 070 or
email ukca@trustdistribution.com.
2. The power adapter is intended to be
correctly oriented in a vertical or floor
mount position. The prongs are not
designed to hold the plug in place if it is
plugged into a ceiling, under-the-table or
cabinet outlet.
