Section 2
System Components
Page 6
Installation Hardware Kit
앫 Contains Schedule 80 NPT pipe nipple fittings
and Grade 8, 3/8-inch SAE bolts for proper
mounting of ABS components to the trailer
frame or reinforced air tanks.
Easy-Stop™ Trailer ABS Warning Label
앫 Provides information about the operation of the
ABS warning lamp and illustrates blink code
fault locations.
앫 Label is self-adhesive and is mounted on the
trailer near the ABS warning lamp.
앫 If there is no warning label on your trailer, let
your supervisor know. Labels are available from
WABCO. Ask for Part Number TP-95172.
MPSI Pro-Link
®
9000 Diagnostic Tool
앫 Provides diagnostic and testing capability for
ABS components.
앫 Requires a cartridge (version 4.0 or higher)
designed for use with WABCO ABS.
The Pro-Link
®
9000 diagnostic tool is not available
from WABCO. Contact Kent-Moore at
800-328-6657 to order.
Figure 2.15
Figure 2.16
