WABCO Easy-Stop Basic User Manual

Page 39
Section 8
Appendixes
Table J — Expert Mode Fault Code (continued)
67X Sensor YE2 Out of Adjustment Adjust sensor.
610X Sensor YE2 Speed Erratic Check for excessive hub
runout, a sensor gap that is too
wide or damage to the
tooth wheels.
73X External Modulator
(Red)
Short to Power Check ABS valve and cable.
Replace as required.
75X External Modulator
(Red)
Cable Break or Open Check ABS valve and cable.
Replace as required.
76X External Modulator
(Red)
Short to Ground or
Cable Damaged
Check ABS valve and cable.
Replace as required.
712X External Modulator
(Red)
ECU/Valve
Assembly Failure
Check ABS valve and cable.
Replace as required.
93X External Modulator
(BU)
Short to Power Check ABS valve and cable.
Replace as required.
95X External Modulator
(BU)
Cable Break or Open Check ABS valve and cable.
Replace as required.
96X External Modulator
(BU)
Short to Ground or
Cable Damaged
Check ABS valve and cable.
Replace as required.
912X External Modulator
(BU)
ECU/Valve
Assembly Failure
Check ABS valve and cable.
Replace as required.
10 3 X ECU/Valve Assembly
Modulator (YE)
Short to Power Check ABS valve and cable.
Replace as required.
10 5 X ECU/Valve Assembly
Modulator (YE)
Cable Break or Open Check ABS valve and cable.
Replace as required.
10 6 X ECU/Valve Assembly
Modulator (YE)
Short to Ground or
Cable Damaged
Check ABS valve and cable.
Replace as required.
10 12 X ECU/Valve Assembly
Modulator (YE)
ECU/Valve
Assembly Failure
Check ABS valve and cable.
Replace as required.
14 2 X ECU Data Erratic Unexpected System.
14 3 X Power Supply Over Voltage Repair vehicle power supply.
14 4 X Power Supply Under Voltage Check vehicle voltage output
and connector.
14 5 X Power Supply Current Low Check for proper ground on
power cable.
14 9 X ECU/Valve Assembly Internal Failure Erase fault.
14 12 X ECU/Valve Assembly Internal Failure Erase fault.
15 9 X Electromagnetic
Interference
Various
Contact WABCO North America
Customer Care, 855-228-3203.
15 12 X ECU/Valve Assembly Internal Failure Contact WABCO North America
Customer Care, 855-228-3203.
X = Number of Fault Occurrences
Blink Code
Component or
Location
Cause or Type
of Fault Solution
1st
Digit
2nd
Digit
3rd
Digit (X)
