BA 1001/1501/2001 us – Edition 3.3 * 12001b610.fm 6-19
Technical data (2001)
6.14 Dimensions model 2001
Fig. 112: Machine dimensions (model 2001)
Main data
Model 2001
Dead weight
1810 kg (3,990 lbs)
Overall height
2650 mm (8'-8'')
Overall height with lowered rollbar
1850 mm (73 in)
Overall height without rollbar
1850 mm (73 in)
Overall width
1485 mm (58 in)
Ground clearance
380 mm (15 in)
Wheelbase
1800 mm (71 in)
Outside turning radius
3500 mm (11'-6'')
Hill climbing ability
45 % theoretically
Safe authorized inclination
20 % in all machine travel
positions
