BA 1001/1501/2001 us – Edition 3.3 * 12001b320.fm 3-3
Operation
Description of 1501S components (overview)
Pos.
Designation
1 Operator seat
2 Control stand
3Skip
4 Swivel centring
5 Swiveling console
6 Tilt cylinder
7 Articulated joint
8 Steering cylinder
9 Rear chassis
10 Engine cover
