15 Technical data
100_0102_td_0002.fm 36
15.1.1 Extension cable
The following points must be observed:
 Only use permitted extension cables.
 Refer to nameplate for details of type designation and voltage of this machine.
 Refer to the following table for the required cross-section area.
WARNING
Warning about voltage.
Serious injuries from electric shock.
 Check power cable and extension cable for signs of damage.
 Only use extension cables for which grounded conductors are connected to the plug
and the coupling (only for machines of protection class I + III, see chapter "Technical
data").
Machine type Voltage
[V]
Extension
[m] (ft)
Cross-section area of
cable
[mm
2
]
AR26/3/230 w 230 1~ <
150 (492.1) 1.0
AR26/3/400 400 3~ <
150 (492.1) 1.5
AR26/3.6/230 US 230 3~ <
150 (492.1) 1.5
AR26/6/042
AR26/6/042 cs
AR26/6/042 3.5kN
42 3~ <
16 (52.5) 1.5
<
26 (85.3) 2.5
<
40 (131.2) 4
<
58 (190.3) 6
AR26/6/250 250 3~ <
150 (492.1) 1.5
Machine type Voltage
[V]
Extension
[m] (ft)
Cross-section area of
cable
[AWG]
AR26/3/230 w 230 1~ < 150 (492.1) 16
AR26/3/400 400 3~ <
150 (492.1) 16
AR26/3.6/230 US 230 3~ <
150 (492.1) 16
AR26/6/042
AR26/6/042 cs
AR26/6/042 3.5kN
42 3~ <
14 (45.9) 16
<
21 (68.9) 14
<
33 (108.3) 12
<
51 (167.3) 10
AR26/6/250 250 3~ <
150 (492.1) 16
