Wacker Neuson AR - Technical Data; Ar63

19 Technical data
100_0102_td_0006.fm 48
19 Technical data
19.1 AR63
Designation Unit AR63/6/250
Item no. 5100004222
Rated current A 3,30
Rated voltage V 250
Rated frequency Hz 200
Rated output kW 1,25
Phases ~ 3
Centrifugal force kN 10,36
Vibrations rpm 6.000
Hz 100
Centrifugal force max. kN 19,03
Length mm (in) 230 (9.1)
Width mm (in) 184 (7.2)
Height mm (in) 188 (7.4)
Weight kg (lb) 13.90 (30.6)
Motor type Induction motor
Class rating l
Protection class * IP67
Storage temperature range °C (°F) -30 – +70
(-22 – +158)
Operating temperature
range
°C (°F) -10 – +50
(+14 – +122)
Housing external
temperature
°C (°F) 80 (176)
Sound pressure level L
pA
**
dB(A) 76
Standard
EN ISO 11201, EN 12649
*
Only guaranteed with a Wacker Neuson power cable.
**
Measured at distance of 1 m (3.2 ft).
