17 Technical data
41 100_0102_td_0007.fm
17.1.1 Extension cable
The following points must be observed:
 Only use permitted extension cables.
 Refer to nameplate for details of type designation and voltage of this machine.
 Refer to the following table for the required cross-section area.
WARNING
Warning about voltage.
Serious injuries from electric shock.
 Check power cable and extension cable for signs of damage.
 Only use extension cables for which grounded conductors are connected to the plug
and the coupling (only for machines of protection class I + III, see chapter "Technical
data").
Machine type Voltage
[V]
Extension
[m] (ft)
Cross-section area of
cable
[mm
2
]
AR43/3/230 v 230 1~ <
150 (492.1) 1.5
AR43/3/400 400 3~ <
150 (492.1) 1.5
AR43/6/042 42 3~ <
10 (32.8) 1.5
<
17 (55.8) 2.5
<
27 (88.6) 4
<
39 (128.0) 6
<
61 (200.1) 10
AR43/6/250 250 3~ <
150 (492.1) 1.5
Machine type Voltage
[V]
Extension
[m] (ft)
Cross-section area of
cable
[AWG]
AR43/3/230 v 230 3~ < 150 16
AR43/3/400 400 3~ <
150 16
AR43/6/042 42 3~ <
916
<
14 14
<
22 12
<
34 10
<
52 8
AR43/6/250 250 3~ <
150 16
