18 Technical data
100_0102_td_0005.fm 44
Designation Unit AR53/9/042 AR53/9/250
Item no. 5100004262 5100004263
Rated current A 14,00 2,40
Rated voltage V 42 250
Rated frequency Hz 150 150
Rated output kW 0,80 0,80
Phases ~ 3 3
Centrifugal force kN 9,11 9,11
Vibrations rpm 9.000 9.000
Hz 150 150
Centrifugal force max. kN 13,77 13,77
Length mm (in) 231 (9.1) 231 (9.1)
Width mm (in) 184 (7.2) 184 (7.2)
Height mm (in) 188 (7.4) 188 (7.4)
Weight kg (lb) 11.62 (25.62) 11.62 (25.62)
Motor type Induction motor
Class rating lll l
Protection class * IP67 IP67
Storage temperature range °C (°F) -30 – +70
(-22 – +158)
-30 – +70
(-22 – +158)
Operating temperature
range
°C (°F) -10 – +50
(+14 – +122)
-10 – +50
(+14 – +122)
Housing external
temperature
°C (°F) 80 (176) 80 (176)
Sound pressure level L
pA
**
dB(A) 77 77
Standard
EN ISO 11201, EN 12649
*
Only guaranteed with a Wacker Neuson power cable.
**
Measured at distance of 1 m (3.2 ft).
