20 Technical data
53 100_0102_td_0008.fm
Designation Unit AR75/6/042 AR75/6/250
Item no. 5000007794 5000007797
Rated current A 32,00 7,50
Rated voltage V 42 250
Rated frequency Hz 200 200
Rated output kW 2,00 2,50
Phases ~ 3 3
Centrifugal force kN 14,05 14,05
Vibrations rpm 6,000 6,000
Hz 100 100
Centrifugal force max. kN 26,56 26,56
Length mm (in) 330 (13.0) 330 (13.0)
Width mm (in) 218 (8.6) 218 (8.6)
Height mm (in) 218 (8.6) 218 (8.6)
Weight kg (lb) 26.80 (59.1) 26.80 (59.1)
Motor type Induction motor
Class rating lll l
Protection class * IP67 IP67
Storage temperature range °C (°F) -30 – +70
(-22 – +158)
-30 – +70
(-22 – +158)
Operating temperature
range
°C (°F) -10 – +50
(+14 – +122)
-10 – +50
(+14 – +122)
Housing external
temperature
°C (°F) 80 (176) 80 (176)
Sound pressure level L
pA
**
dB(A) 79 79
Standard
EN ISO 11201, EN 12649
*
Only guaranteed with a Wacker Neuson power cable.
**
Measured at distance of 1 m (3.2 ft).
