Description
T01029GB.fm 25
2. Description
2.1 Max. admissible inclination
2.2 Description of function
2.2.1 The vibration required for compaction is produced by the exciter (13)
which is firmly joined to the lower mass (5). This exciter (13) is
designed as a central vibrator with aligned vibrations. Such a principle
permits the direction of vibration to be changed by turning the eccentric
weights (15). In this way an infinitely variable transition between
vibration in forward motion , at standstill and in reverse motion is
possible. This process is hydraulically controlled with the operating
control handle (6) on the centre pole head (7).
If the machine looses its hydraulic oil it will start traveling backwards
(danger of crushing).
