4-26 BA E16 en* 1.0 * E16_10_400.fm
4 Putting into operation
Operation overview
Fig. 106 Control elements
Switch panel on the
right
Jog Dial control unit
(Tier IV)
Switch panel on the left
4321
7
9
10
8
6
5
Designation See page
1 Tilt the upper carriage (VDS/option)
5-72
2 Working lights
5-13
3 Safe load indicator (option)
5-35
4 Hydraulic quickhitch (option)
5-41
5 Window wiper/wash system (cab)
5-16
6 Rotating beacon (option)
5-15
7 Blower (cab)
5-18
8 Air conditioning (option)
5-17
9 Automatic engine speed setting
5-5
10 Jog dial control unit tier IV
4-27
