BA E16 en* 1.0 * E16_10_400.fm 4-25
Putting into operation 4
Designation See page
1 Accelerator pedals/drive levers
5-1
2 Boom swivel pedal
5-26
3Horn
5-14
4 Cell phone compartment
--
5 Control lever on the right
--
6 Speed range selection
5-4
7 Stabilizer-blade lever
5-25
8 Temperature controller (cabin/version 1)
5-17
9 Display element
4-28
10 Right armrest
4-11
11 Oil flow AUX I rotary switch (proportional controls)
5-31
12 Ignition lock
4-38
13 Switch panel on the right
4-26
14 Radio (option – see operator’s manual for radio)
--
15 Cigarette lighter (cabin)/12V connection (canopy)
4-22
16 Document box (option)
4-22
17 Operator seat
4-8
18 Gas lever (tier IV: manual throttle function via jog dial)
5-2
19 Armrest (left)
4-11
20 Oil flow AUX II rotary switch (proportional controls)
5-31
21 Switch panel on the left
4-26
22 Foot-operated push button for hydraulic quickhitch (option)
5-42
23 ISO/SAE changeover (option)
5-21
24 Control lever on the left
--
25 Control lever base
4-39
26 Multifunctional display tier IV
4-28; 4-35
27 Dozer blade (swiveling dozer blade option)
5-25
28 Jog dial
4-27
29 Drinks holder
--
30 USB connection
4-22
31 Temperature controller (cabin/version 2)
5-17
