Technical data EH 9
48
Extension cable for the US market:
Example
You utilize an EH 9/230 and want to use an extension cable with a length of 50 m
(164 ft).
The machine has an input voltage of 230 V.
According to the table, the extension cable must feature a cross-section area of
4,0 mm
2
(AWG 12).
Voltage
[V]
Extension
[ft]
Cross-section
area of cable
[AWG]
110–127 1~ < 36 14
< 58 12
< 89 10
220–240 1~ < 75 16
< 121 14
< 190 12
< 302 10
