Wacker Neuson GV 7000A User Manual

11 Technical data
44
100_0402_td_0004.fm
11.2 GV 7003
Designation Unit GV 7003A
Item number 5100002155
Peak performance 1~
(LTP)
kW 3.4
Peak performance
3~(LTP)
kW 6.0
Continuous (prime) power
output 1~(COP)
kW 3.2
Continuous (prime) power
output 3~(COP)
kW 5.7
Net installed power (PRP) kW 5.6
Length mm 729
Width mm 500
Height mm 536
Weight kg 81
Operating weight kg 86
Generator model NSM T100SC
Insulation class H
Output current 1~ A 14.1
Output frequency Hz 50
Power factor cos 0.9
Nominal speed rpm 3,000
Power factor 3~ cos 0.8
Phases ~ 3
Type of mains Protective breaker
Total harmonic distortion
(THD)
%6
Start-up behavior (ICC) In 3-4
Voltage accuracy % 6
Output current 3~ A 10.8

Wacker Neuson GV 7000A Specifications

General

Brand	Wacker Neuson
Model	GV 7000A
Category	Portable Generator
Language	English
