PST2 400 Installation
wc_tx001980gb.fm 15
3 Installation
3.1 Components
Ref. Description Ref. Description
1 Lifting handle 9 Oil plug
2 Mechanical seal 10 Dust seal
3 Lubricant 11 Sleeve
4 Oil housing 12 Impeller
5 Coupling 13 Stirrer nut
6 Volute 14 Strainer
7 Gasket 15 Oil lifter
8 Cable assembly
wc_gr001699
8
1
9
10
12
13
14
6
11
15
2
5
3
