PST2 400 Installation
wc_tx001980gb.fm 19
Note: The reference insulation resistance (20M
or greater) is the value
when the pump is new or has been repaired. For the reference value after
installation, see the Periodic Maintenance table.
3.5 IInstalling the Float (if equipped)
3.5.1 Set the length of the float lead wire to the dimension indicated below.
Failure to set the correct lead wire length will lead to improper
operation of the pump.
NOTICE: Install the float so that it moves freely up and down. If the
float binds or catches, it will cause the pump to operate improperly.
Pump model Length “L”
PSTF2 400 150 mm (5.9 in.)
wc_gr005664
