PST2 400 Schematics
wc_tx002025gb.fm 39
7 Schematics
NOTICE: If connected to a circuit protected by a fuse, use a time-delay fuse
with this pump.
Ref. Description Ref. Description
1 Capacitor 5 Frame grounding
2 Main coil 6 Ground
3 Auxiliary coil 8 Float switch (normally open con-
tact)
4 Miniature protector
wc_gr006190
PSTF2 400
PST2 400
W
W (L)
6
5
8
1
3
2
4
R(Br)
R
Y/G
B
LL
R
R
1
W
W
B
L
3
2
5
4
6
G
G/Y
G/Y
