Operation PT 6L
24 wc_tx001597gb.fm
4 Operation
4.1 Preparing the Machine for First Use
Preparing for first use
To prepare your machine for first use:
4.1.1 Make sure all loose packaging materials have been removed from the
machine.
4.1.2 Check the machine and its components for damage. If there is visible
damage, do not operate the machine! Contact your Wacker Neuson
dealer immediately for assistance.
4.1.3 Take inventory of all items included with the machine and verify that
all loose components and fasteners are accounted for.
4.1.4 Attach component parts not already attached.
4.1.5 Add fluids as needed and applicable, including fuel, engine oil, and
battery acid.
4.1.6 Move the machine to its operating location.
4.2 Control / Component Descriptions
See Graphic: wc_gr003183
Ref. Description Ref. Description
1 Engine oil dipstick 14 Engine oil filter
2 Fuel filter 15 Battery box
3 Manual fuel pump lever 16 Trailer hitch
4 Engine oil drain plug 17 Jack stand
5 Engine throttle solenoid 18 Rear stabilizers
6 Control panel 19 Drain cover
7 Ignition switch 20 Front impeller cover
8 Hour meter 21 Suction port
9 Bearing/Seal housing 22 Priming cover
10 Lifting point 23 Discharge port
11 Engine oil fill cap 24 Fuel fill cap
12 Inspection cover 25 License plate holder
13 Air cleaner 26 Circuit breaker
