Wacker Neuson PT 6L - Pump; Lubrication; Trailer and Skid

PT 6L Technical Data
wc_td000099gb.fm 51
6.2 Pump
6.3 Lubrication
6.4 Trailer and Skid
Item No.
PT 6LT
0007175
PT 6LS
0007174
Pump
Weight
kg (lbs.)
1090 (2400) 850 (1870)
Max. suction lift
m (ft.)
7.5 (25)
Max. total head
m (ft.)
30.5 (100)
Max. discharge
m³/h (gpm)
295 (1300)
Suction / discharge dia.
mm (in.)
150 (6)
Max. solid size
mm (in.)
50 (2)
Item No.
PT 6LT
0007175
PT 6LS
0007174
Lubrication
Engine
type / qty.
SAE 15W40 CD Rated / 5.0 L (5 qts.)
Pump seal housing
type / qty.
SAE 15W40 / 800ml (27oz.)
Pump bearing housing
type / qty.
SAE 15W40 / 470ml (16oz.)
Item No.
PT 6LT
0007175
Trailer
Power take-off
type
Direct Drive with Flex-Coupling
Trailer tounge weight
kg (lbs)
75 (165)
Gross vehicle weight
Rating
kg (lbs)
1588 (3500)
Tire size 205 / 75D-14
Tire load Rating C
