PT 6L Maintenance
wc_tx001598gb.fm 39
5.6 Lubrication
See Graphic: wc_gr000057 & wc_gr001187
Check the engine oil level daily. Add oil as required.
To check oil:
Place the machine on a level surface, remove the dipstick and check
that the oil level is at the top mark. Add oil through the oil filler cap (a)
on top of engine, checking occasionally with dipstick; DO NOT overfill.
Suggested oil grades:
Use only diesel engine oil API service rating CD or equivalent.
ENGINE OIL VISCOSITY GRADE - AMBIENT TEMPERATURE
Ambient
Temperature
(Multi-grade)
-25ºC
(-13ºF)
-15ºC
(5ºF)
-20ºC
(-4ºF)
15ºC
(59ºF)
30ºC
(86ºF)
0ºC
(32ºF)
SAE 10W-30
SAE 15W-40, 20W-40
SAE 5W-20
wc_gr000057
wc_gr001187
b
c
a
