PT 6L Operation
wc_tx001597gb.fm 27
4.6.7 Attach the suction strainer to the suction hose to prevent large debris
from being pulled into the pump.
4.6.8 Prime the pump. To do so, open the cover (c) at the top of the pump
and fill the pump housing with water. The pump will not prime unless
this is done.
4.7 Starting
See Graphic: wc_gr001166
4.7.1 Loosen the throttle lever knob (c) and set the engine throttle (d) to high
speed. Tighten the throttle lever knob.
4.7.2 Open the cover on the battery box (a) and turn and hold the ignition key
(b) to the ON position until the glow plug light on the control panel goes
out. Then, turn the ignition key to the START position. Release the key
after the engine starts. It will spring back into the ON position.
Note: The engine will not start if the oil pressure is too low or the
cylinder head temperature exceeds the preset value.
wc_gr001165
a
b
f
c
d
e
g
