Putting into operation 4
BA TH412 * 06/2017 * 4512_4-3_Warnleuchten_en.fm
4-35
Rocker switch for "additional hydraulic connec-
tions on the mast" (4th control circuit) (optional)
The rocker switch 47 is located in Rocker switch panel 4.
Additional hydraulic connections on the mast can be
operated with this function. This function is required if the
standard hydraulic connections are not sufficient for
certain attachments.
➥
Operate additional hydraulic connections on the
mast (4th control circuit) on page 5-89
Rocker switch for "rear hydraulic connections"
(option)/Rocker switch for "PTO shaft" (optional)
The rocker switch 48 is located in the Rocker switch
panel 4. The rocker switch is used to actuate the hydraulic
connections on the rear or the PTO shaft depending on
the outfitting of the vehicle.
➥
Operating the rear hydraulic connections with a
switch on page 5-93
➥ Operating the PTO shaft on page 5-99
