5-40
BA TH412 * 06/2017 * 4512_5-9_Arbeitshydraulik_en.fm
5 Operation
Locking the loader unit
Accident hazard due to unintentional control lever
operation during machine travel on roads!
Operating the loader unit control lever unintentionally can
cause accidents and injury.
► Lock the lifting unit control lever during road travel.
► Lock the lifting unit control lever before leaving the
machine.
► First sit down on the operator seat. Then unlock the
lifting unit control lever.
The loader unit control lever can be secured against
unintentional operation by means of a lock. The loader
unit cannot be operated if the lock is engaged. A locked
loader unit is not indicated by indicator lights, but by the
position of the control lever (
Fig. 72).
Operating the loader unit lock
The loader unit is locked by operating control lever 1.
• Move control lever 1 toward A:
➥ The lock is engaged.
• Move control lever 1 away from A:
➥ The lock is disengaged.
