5 Operation
Hydraulic lock for attachments (option)
Operating the hydraulic lock for attachments
The hydraulic lock for attachments is operated with the
additional control lever 6.
1. Move the additional control lever 6 toward R.
➥ The quickhitch is locked.
2. Move the lock a in the rocker switch 40 (in Rocker
switch panel 1) towards b and hold down the rocker
switch 40.
3. Move additional control lever 6 toward L.
➥ The quickhitch is unlocked.
40
R
L
Fig. 74
6
0
1
b
a
