Maintenance
Maintenance work 9.3
35
[en] | 02/2020 | 5100056064 | VP | Operator’s manual
9.3.4 Checking and topping up engine oil level
NOTICE
Danger of engine damage!
► Only change the oil when the engine is at operating temperature.
► Only use engine oil with the correct specification,
see Technical data
on page 42
.
1. Remove dirt.
2. The machine must be horizontal.
3. Unscrew engine oil dipstick 1.
4. Wipe the engine oil dipstick with clean and fiber-free rags.
5. Tighten the engine oil dipstick again.
6. Unscrew the engine oil dipstick again.
7. Check engine oil fill level.
ð If the engine oil level is at the lower fill level limit 3, top up engine
oil if necessary,
see Technical data on page 42
.
ð Fill engine oil to the upper fill level limit 2, do not overfill.
▪ Tighten the engine oil dipstick again.
9.3.5 Replacing engine oil
1. Remove dirt.
2. Provide a suitable container for draining the used oil.
3. Unscrew engine oil dipstick 1.
9
