Wacker Neuson VP1030A-CE - Machine Data; Sound and Vibration Measurements

wpm_td000708gb.fm
34
7.2 Machine Data
VP1030A-CE
VP1030AW-CE
Plate
Dry Weight
kg (lbs.)
52 (114.4)
56(116.6)
Water Tank Capacity
l (qts.)
7.6 (8)
Exciter speed
rpm
5800 ± 100
Exciter lubrication
ml (oz.)
150 (5)
Motor oil
7.3 Sound and Vibration Measurements
The required sound specification, Paragraph 1.7.4.f of 89/392/EEC Machinery
Directive, is:
► The guaranteed sound power level (L
WA
) = 105 dB(A).
► The sound pressure level at operator’s location (L
pA
) = 89 dB(A).
These sound values were determined according to ISO 3744 for the sound
power level (L
WA
) and ISO 6081 for the sound pressure level (L
pA
) at the
operator’s location.
The weighted effective acceleration value, determined according to EN ISO 5349,
is approximately 4.78 m/s
2
.
The sound and vibration measurements were obtained with the machine operating
on crushed gravel at nominal engine speed.
VP1030A/AW Technical Data
