27
appendix
PS 3.25
12.3 SPRAY GUN ACCESSORIES
Flat jet adjusting tip
up to 250 bar (25 MPa
Contact protection
for the at jet adjustment tip
Order No. 0097 294
Tip extension with slewable knee joint
(without tip)
Tip extension
15 cm, F-thread, Order no. 0556 051 15 cm, G-thread, Order no. 0556 074
30 cm, F-thread, Order no. 0556 052 30 cm, G-thread, Order no. 0556 075
45 cm, F-thread, Order no. 0556 053 45 cm, G-thread, Order no. 0556 076
60 cm, F-thread, Order no. 0556 054 60 cm, G-thread, Order no. 0556 077
Tip marking Bore mm
Spray width at about 30 cm removal of
spray object
Pressure 100 bar (10 MPa)
Use
Flat jet adjusting tip
Order No.
15 0.13 - 0.46 5 - 35 cm Paints 0999 057
20 0.18 - 0.48 5 - 50 cm Paints, llers 0999 053
28 0.28 - 0.66 8 - 55 cm Paints, dispersions 0999 054
41 0.43 - 0.88 10 - 60 cm Rust protection paints -
dispersions
0999 055
49 0.53 - 1.37 10 - 40 cm Large-area coats 0999 056
Length: 100 cm Order no. 0096 015
Length: 200 cm Order no. 0096 016
Length: 300 cm Order no. 0096 017
