1
HOUSEHOLD
OIL
2
3
a
HOUSEHOLD
OIL
4
5
EN
19
LONG TERM STORAGE
i
Follow these steps to prepare your sprayer for long-
term storage.
YOU WILL NEED
Light household oil / All Guard
Rags
Two adjustable wrenches
i
The suction tube should still be removed from the
end of the previous section and the PRIME/SPRAY
knob should be in the PRIME position.
1. Remove the spray hose from the spray gun. Tip the spray gun
upside down and pour a few drops of All Guard inside the gun
housing.
A light oil can be substituted (such as 10W30 motor oil or
vegetable oil for example).
2. Place a wrench on the outlet valve to secure it. Using the
second wrench, remove the spray hose.
3. Fill a cup or other container with two ounces of All Guard and
submerge the inlet valve (a) into the oil.
A light oil can be substituted (such as 10W30 motor oil or
vegetable oil for example).
4. Cover the outlet valve with a rag. Turn the pressure control
knob to ‘2’ and let the pump run for ve seconds.
Turn power OFF.
5. Replace suction tube. Wipe entire unit, hose, and spray gun
to remove accumulated spray material.
At
tention
Store the unit indoors with the power cord wrapped
around the cart handle or stand.
