WAGNER EP 3000 User Manual

Item Part No. Part No. Description Qty.
230 V 400 V
1 0291 531 0291 531 Covering 1
2 9802 529 9802 529 Oval head screw 4
3 0291 536 0291 536 Hook 1
4 9821 505 9821 505 Spring washer 6
5 9810 107 9810 107 Hexagon nut 2
6 0256 396 0256 396 Type plate 2
8 0089 372 0089 372 Washer 2
9 9800 315 9800 315 Fillister head screw 6
10 9821 508 9821 508 Spring washer 1
11 9810 110 9810 110 Hexagon nut 1
12 0291 532 0291 532 High pressure hose 1
13 0090 447 0090 447 Angled connection 1
15 ––––––– ––––––– Material feed pump, see page 39
16 9850 643 9850 643 Hose clip 1
17 0258 308 0258 308 Tube 1
18 0253 244 0253 244 Filter 1
19 9800 115 9800 115 Hexagon bolt 1
20 9800 320 9800 320 Fillister head screw 2
23 ––––––– ––––––– High pressure filter, see page 40
24 0291 541 0291 541 Pressure regulator 1
25 9953 670 ––––––– Motor safety switch 230 V~, 50 Hz, 16 A 1
––––––– 0256 348 Motor safety switch 400 V, 50 Hz, V 3~, 8 A 1
26 0291 438 0291 438 Cover 1
27 9802 250 9802 250 Oval head screw 4
28 9802 252 9802 252 Hexagon bolt 4
29 9951 652 ––––––– Mains cable HO7 RN-F3G2,5, 6 m 1
––––––– 0256 214 Mains cable HO7 RN-F5G1,5, 6 m 1
30 9952 800 ––––––– Capacitor 60 MF / 400 V (230 V~, 50 Hz) 1
31 ––––––– ––––––– Trolley, see page 40
38
Spare parts list – high-pressure spraying unit WAGNER EP 3000
(Spare parts diagram, see page 66)
