15
EPG-SPRINT.
OPERATING MANUAL
VERSION 08/2010
ORDER NUMBER DOC 2305222
Pneumatic:
Compressed air input pressure 0.6-0.8 MPa; 6-8 bar; 87-116 psi
Air quantity max. 15 m³/h
Summation of the dosage and feed air 2-6 m³/h
Gun air 0.05-4.0 m³/h
Required compressed air quality as per
ISO 8573.1
3.5.2
Connection hose diameter 8 mm; 0.315 inches
Ambient conditions:
Operating temperature range 5-45°C; 41-113°F
SIHI_05034_ENG
WARNING
Outgoing air containing oil!
Risk of poisoning if inhaled.
Provide water-free and oil-free compressed air (quality standard
3.5.2 as per ISO 8573.1) 3.5.2 = 5 μm / +7°C; 44.6°F / 0.1 mg/m³.
SIHI_05054_ENG
CAUTION
Compressed air quality, accessories
Danger of equipment damage.
Operate the control unit only with the prescribed compressed air quality.
Only use the control unit with original Wagner accessories.
Disregard of these conditions leads to expiring the warranty.
Ambient conditions:
If low temperature powders are used,the ambient temperature may have to be lower than
30°C; 86°F.
Volume measures:
For volumes,specified in Nm³ (standard cubic meters). One cubic meter of a gas at 0°C; 32°F
and 1.013 bar is called norm cubic meter. 1 Nm³/h = 35.3ft³/h; 1 bar = 14.504 psi.
