WAGNER EPG-SPRINT - Changing and Saving Programs

34
EPG-SPRINT.
2x
P_01125
OPERATING MANUAL
VERSION 08/2010 ORDER NUMBER DOC 2305222
Programs 1-4 can be selected and saved directly using program buttons 5-8. Once the
program required has been called up, the individual coating parameters can be called up
and changed using the corresponding selection buttons. The individual parameters are
described in chapters 6.5.1-6.5.8. When a parameter is changed, the LED on the left of the
program button fl ashes to indicate that a parameter value has been changed.
The process for saving parameters is described below.
● To reuse the originally set values, press the program button briefly. The modifi ed values
are not taken over.
● To save the modified values, press the appropriate program button and hold for
approx. 2 seconds until the LED beside the button flashes quickly. The modified values
are then saved.
7
8
5
6
6.4 CHANGING AND SAVING PROGRAMS
6.4.1 PROGRAMS NO. 1-4
