FinishControl 3500
GB
SPARE PARTS AND ACCESSORIES
15.2 SPARE PARTS FINISHCONTROL 3500 FIG. 26
POS.
ORDER NO.
DESIGNATION
1 2343 946 Cover of air lter compartment
2 2343 947 Air lter (3 pcs.)
3 2343 948 Fixture for shoulder strap (incl. screws)
4 2341 187 Carrying strap
5 0514 209 Cleaning brush
6 2324 745 Funnel (3 pcs.)
7
2344 041
Velcro to secure the power cable
8 2341 100 Transport case
15.3 SPARE PARTS STANDARDSPRAY SPRAY ATTACHMENT YELLOW FIG. 27
POS.
ORDER NO.
DESIGNATION
1 2321 879 StandardSpray spray attachment (yellow) (with 1000 ml container)
2 2314 594 Spray jet width adjusting lever
3 2314 591 Spray jet adjustment ring
4 2332 577 Union nut (yellow)
5
2317 807
Air cap
6
2314 585
Air screen
7
2317 423
Nozzle (S 4.1)
8
2323 934
Nozzle seal
9
2304 027
Ventilating hose, valve cover, diaphragm
10
0417 308
O-ring of spray attachment
11
2324 250
Body of gun (including position 8-10)
12
2319 223
Container seal
13
2319 222
Feed tube
14
2324 248
2324 249
Fine feed tube lter (red, 5 pc.)
Coarse feed tube lter (white, 5 pc.)
15
2322 451
Container with cover 1000 ml
2315 539
Lubricating grease
