2 EXPLANATORY DIAGRAM FIG. 1
3 THE WAGNER CLICK&PAINT SYSTEM
With the Wagner Click&Paint System, the front part of the gun (spray attachment) can be replaced quickly and easily.
This enables a rapid material change without cleaning, and ensures that the right tool is available for every material and applica-
tion.
The following spray attachments are available:
Spray attachment Area of application
StandardSpray (yellow)
Order No. 2321 879
Spray attachment with slit nozzle and 1000 ml stainless steel container. Processes all standard
paints.
FineSpray (brown)
Order No. 2321 877
Spray attachment with round nozzle and 1000 ml stainless steel container. Ideal for low-viscosity
paints and glazes.
WallSpray (white)
Order No. 2321 880
Dispersion spray attachment with slit nozzle and 1400 ml plastic container. Designed for processing
dispersions and latex paint.
3.1 DISASSEMBLY OF THE SPRAY GUN
For assembly, insert the spray attachment into the FC 3500 so that the two arrows point at each other.
Turn the FC 3500 90° in the arrow direction until it audibly engages. (Fig. 2)
To remove the spray attachment, push the catch (Fig. 2, A) beneath the trigger down and turn the spray attachment by 90°.
EXPLANATORY DIAGRAM/ CLICK&PAINT SYSTEM
1 Nozzle
2 Air cap
3 Spray jet width adjusting lever (shaping air)
4 Spray jet level adjusting ring (vertical/horizontal)
5 Union nut
6 Spray attachment complete
7 Material volume regulation
8 Fixture for shoulder strap
9 Air lter cover lock
10 Air lter cover
11 Air volume control
12 Power cable
13 Click&Paint catch
14
Trigger (actuates turbine starting switch
material is
conveyed)
15 Container
16 Suction tube
17 Container seal
18 Valve
19 Ventilating hose
20 Cleaning brush
21 Fine feed tube lter (red)
Coarse feed tube lter (white)
22 Funnel (3 pcs.)
23 Replacement air lter (3 pcs.)
24 Carrying strap (for device and transport case)
25 Transport case
26 Velcro to secure the power cable
